BREYER TopLine
Extrusion line for the production of tube sleeves
High performance tube extrusion –
Produce tube sleeves in a sustainable and flexible way with a high level of performance
Today, speed and quality are top priority in many production processes. It's good if you can refer to a technology that delivers good quality even at high speeds. Clients from the world of cosmetics, which has high standards, know to appreciate this fact.
Perfect looks and tactile qualities often decide the success or failure of a product.
Still, economic efficiency cannot be neglected in the production
process.
New, Clear Design
New machine aesthetics that match the tube products
Intelligent Energy Management
- for saving up to 20% in energy costs
- Gearless direct drives / water cooled torque drives
- Fan units with flaps
- Heat insulation for cylinder and die head
- Slow-down and standby function
- Peak reduction
The intelligent way to save energy and cost please find here...
Process Data Recording
Monitoring and controlling the adjustment parameters and production data, ideal recipe management and considerably higher repeatability of production data resp. product qualities.
New Operating Panel · Interface
- Clear and user-friendly software organized in various steps/levels
- Different level steps
- Recipe management
- Quality management
- Service page · teleservice
- Modular setting
Advantages
- Clear design meets tube aesthetics
- Cost, energy savings and noise reduction modules
- Different line configurations and production sizes for mono and multilayer tubes
- High performance up to 45 m/min.
- State-of-the-art drive technology
- User-friendly and modern operating panel
- New arrangement of components – maintenance-friendly and space-saving
- Quality control units and process data recording to secure the tube quality
- Noise reduction: of approx. 11 dB (A)
Technical data
| Tube diameter: | 13 – 60 mm |
| Length: |
30 – 250 mm |
| Performance: |
80 – 300 tubes/min |
| Materials: |
LDPE, LLDPE, MDPE, HDPE, PP, PCR/PIR/Bio, Mixtures. Special materials on request |
| Variations: | Single - and multilayer, up to 7 layers, with window |
Examples of application
